Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
1 / 5
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System
Parking Management System Entry Station RFID Access Control Parking System

Parking Management System Entry Station RFID Access Control Parking System

Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

📋 Basic Information
Model NO.
CM3
Material
Aluminum Alloy
Type
Combination Lock
Style
European
Shape
Mortise Door Lock
Anti-theft Standard
A
Backset
70mm
Power
3V, 4 * Battery
🔍 Product Overview
Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi-technology platform. It provides an ultra-low battery-operated power consumption design, which contains the latest wireless interfacing and multiple identification technologies for customized design of access control, wireless electric lock, canteen management, asset tracking, and different handheld applications.
Smart CM3 supports almost all RFID 13.56MHz contactless technologies, including DESFire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials for mobile applications. Together with supporting Arm® TrustZone® and securable I/Os features, it meets high-security application requirements.
Product Overview
✨ Product Features
Feature 1
Feature 2
Feature 3
🚀 Advantages
  • ✔ Support 13.56MHz Desfire EV1/EV2/EV3 and NFC
  • ✔ Support Arm® TrustZone® for high security
  • ✔ Rich I/O port for electric lock control
  • ✔ With memory for local data storage
  • ✔ Economic solution for battery powered ultra-low power consumption reader
  • ✔ Supports BLE 5.4 Zigbee, Thread/Matter/MQTT protocol
  • ✔ Embedded software development with Body detection function
Advantages Visualization
📊 Specifications
Memory4M BYTE
Power SupplyUSB or 3V / 4 * battery
RFID ISO Standard13.56MHz ISO14443A, ISO15693 and ISO18092; Mifare Classic, DESfire EV1/EV2/EV3, Ultralight C, Mifare plus S/X, NFC tag, HID iCLASS CSN
Secure InterfaceOptional SAM slot ISO7816; Support SAM AV2 for encryption; Secure IC for MCU protection EAL5+ Level
Mobile CommunicationNFC mobile phone, BLE 5.3
Keypad12 digit mechanical keypad
InterfacesWiFi, BLE 5.3 (Master & Slave, Beacon, Thread, Zigbee, Mesh), USB
IndicatorsBuzzer and Bio-color LED
Input/OutputGPI/O * 8
Operating Temp-20ºC ~ 60ºC
ConfigurationConfiguration card, reader tool software or factory configured readers
🏢 About Us
About Us
❓ Frequently Asked Questions
Q: What wireless protocols does the Smart CM3 support? A: It supports BLE 5.3/5.4, WiFi, Zigbee, Thread, Matter, and MQTT protocols for versatile connectivity.
Q: Can this device be used with mobile phones? A: Yes, it supports both NFC and BLE mobile credentials for seamless mobile application integration.
Q: What is the power requirement for the CM3? A: The device is designed for ultra-low power consumption and can be powered by a 3V supply (4 batteries) or via USB.
Q: Does it support high-security encryption? A: Yes, it features Arm® TrustZone® support and a secure IC for MCU communication protection at the EAL5+ level.
Q: What types of RFID cards are compatible? A: It is compatible with a wide range of 13.56MHz technologies including Mifare Classic, DESfire EV1/EV2/EV3, and HID iCLASS CSN.
Q: What is the operating temperature range? A: The device operates reliably in temperatures ranging from -20ºC to 60ºC.
