Customization: Available
After-sales Service: Technical Support & Customization Service
Warranty: 1
Send Inquiry

Product Description

Basic Specifications
Model NO.CM3
MaterialAluminum Alloy
TypeCombination Lock
StyleEuropean
ShapeMortise Door Lock
Anti-theft StandardA
Backset70mm
UsageHousehold Door Locks, Bedroom, Channel Lock
RFIDMIFARE Plus, MIFARE, DESFire EV1/EV2, ISO14443b
CommunicationWiFi, BLE 5.3, USB, Zigbee, Thread
Power3V, 4 * Battery / USB
Product Overview

Smart CM3 is the new generation of BLE 5.4 wireless high-performance multi-technology platform. It provides an ultra-low battery-operated power consumption design, containing the latest wireless interfacing and multiple identification technologies for customized access control, wireless electric locks, and asset tracking.

It supports almost all RFID 13.56MHz contactless technologies, including DESFire EV1/EV2/EV3. It also supports NFC and BLE Mobile credentials. With Arm® TrustZone® and securable I/Os features, it meets the highest security standards.

Smart CM3 Overview
Key Features & Visuals
Feature 1 Feature 2 Feature 3
Core Advantages
🛡️
High Security: Support Arm® TrustZone® for advanced hardware-level security protection.
🔋
Ultra-Low Power: Economic solution for battery-powered readers with optimized power consumption.
📱
Versatile Connectivity: Supports BLE 5.4, Zigbee, Thread, Matter, and MQTT protocols.
💾
Local Storage: Equipped with internal memory for local data storage and management.
⚙️
Rich Interfaces: Includes body detection functions and rich I/O ports for electric lock control.
Technical Advantages
Detailed Specifications
Memory4M BYTE
RFID Standards13.56MHz ISO14443A, ISO15693, ISO18092; Mifare Classic, DESFire EV1/EV2/EV3, NFC Tag
Secure InterfaceOptional SAM slot ISO7816; Support SAM AV2 for EAL5+ encryption
Keypad12 Digit Mechanical Keypad
IndicatorsBuzzer and Bio-color LED
Operating Temp-20ºC ~ 60ºC
ConfigurationConfiguration card, software tool, or factory pre-configured
Technical Details
Frequently Asked Questions
Q: What types of RFID cards are compatible with the Smart CM3? A: It supports a wide range of 13.56MHz technologies including Mifare Classic, DESFire EV1/EV2/EV3, Ultralight C, and HID iCLASS CSN.
Q: Does the device support mobile phone access? A: Yes, it supports both NFC mobile phone communication and BLE 5.3/5.4 for mobile credentials.
Q: How is the Smart CM3 powered? A: The device can be powered via a 3V battery setup (4 * batteries) or through a USB interface.
Q: What wireless protocols are available for integration? A: It supports BLE 5.3/5.4 (Master & Slave), Zigbee, Thread, Mesh, and Matter protocols for versatile IoT integration.
Q: Is the system suitable for high-security applications? A: Absolutely. It features Arm® TrustZone® technology and EAL5+ level secure IC for protected MCU communication.
Q: What is the operating temperature range? A: The Smart CM3 is designed to operate reliably in environments ranging from -20ºC to 60ºC.
